Olympus UPLANFL 40x Phase Contrast Objective
SKU: UPLFL40XPH
2-Year Warranty
Full coverage
Expert Support
Technical help
OLYMPUS UPLANFL 40X PHASE CONTRAST OBJECTIVE
Achieve high-resolution phase contrast imaging with this premium plan fluorite oil immersion objective, featuring:
- 🔬 40x magnification with PH2 phase contrast for detailed cellular visualization
- 🌈 Plan fluorite (UPLANFL) optical design for superior flatness and color correction
- 🎯 0.75 numerical aperture (oil) for exceptional resolution
- 📏 0.51mm working distance for high-magnification applications
- 🔧 RMS thread compatible with infinity corrected microscopes
- ⭐ Excellent condition with flawless optics
🔧 Product Description
The Olympus UPLANFL 40X PH2 phase contrast objective is specifically engineered for high-resolution phase contrast microscopy with superior optical performance using oil immersion. The plan fluorite (UPLANFL) optical design combines plan (flat-field) correction with fluorite elements, delivering exceptional image flatness across the entire field of view with superior chromatic aberration correction. Phase contrast microscopy enhances contrast in transparent, unstained specimens by converting phase shifts in light passing through the specimen into amplitude changes, making cellular structures visible without staining. The PH2 designation indicates this objective is optimized for use with 40x phase contrast condensers. At 0.75 numerical aperture with oil immersion, this objective provides exceptional resolution for detailed cellular imaging at high magnification. Oil immersion eliminates light loss at the glass-air interface, enabling maximum light-gathering capability and resolution. The RMS thread ensures compatibility with Olympus infinity corrected microscope systems. Excellent condition with flawless optics ensures optimal imaging performance and reliable operation for demanding research, clinical, and laboratory applications.
🔎 Typical Applications
- High-resolution phase contrast microscopy with oil immersion
- Cell biology and developmental biology
- Clinical and diagnostic microscopy
- Transparent and unstained specimen imaging
- Research and advanced laboratory microscopy
- Digital imaging and photomicrography
📊 Key Specifications
| Specification | Details |
| Model Number | UPLANFL 40X PH2 |
| Magnification | 40x |
| Optical Design | Plan fluorite (UPLANFL) |
| Phase Contrast | PH2 |
| Numerical Aperture (NA) | 0.75 (oil) |
| Working Distance | 0.51mm |
| Thread Type | RMS |
| Compatibility | Infinity corrected microscopes |
| Condition | Excellent with flawless optics (pre-owned) |
| Primary Advantage | Plan fluorite optics with oil immersion for exceptional resolution |
University purchase orders are welcomed and accepted. Contact us for institutional pricing and procurement assistance.
