CFI SR HP Plan Apochromat Lambda S 100X Silicone Objective
SKU: MRD73950
2-Year Warranty
Full coverage
Expert Support
Technical help
Nikon CFI SR HP Plan Apochromat Lambda S 100X Silicone Immersion Microscope Objective
🔬 Ultra-premium SR HP Plan Apochromat objective for super-resolution and deep tissue imaging
🎯 100X magnification with exceptional 1.33 numerical aperture for maximum resolution
🌈 Superior apochromatic correction from Nikon's Lambda S series
🧪 Silicone immersion design optimized for 3D cell cultures and thick tissue samples
📏 0.30mm working distance (at 23°C) for deep tissue penetration
🔧 M25 thread compatible with Nikon CFI infinity-corrected microscope systems
✨ New condition
🔧 Product Description
The Nikon CFI SR HP Plan Apochromat Lambda S 100X represents the pinnacle of objective design for super-resolution microscopy and deep tissue imaging. As part of Nikon's SR HP (Super-Resolution High Performance) Lambda S series, this objective combines apochromatic correction with silicone immersion technology, delivering exceptional optical performance for imaging 3D cell cultures and thick tissue samples at depth. The silicone immersion medium (refractive index ~1.40) closely matches the refractive index of biological specimens, dramatically reducing spherical aberration when imaging deep into thick samples compared to oil or water immersion. With an ultra-high numerical aperture of 1.33, this objective provides outstanding resolution and light-gathering efficiency for super-resolution techniques including SIM, STORM, and PALM. The Lambda S designation signifies Nikon's advanced optical design optimized for extended spectral range and superior flatness of field. The 0.30mm working distance at 23°C provides adequate clearance for imaging into thick specimens. Compatible with Nikon's CFI infinity optical system, this objective integrates seamlessly with Eclipse Ti2, Ni-E, and A1 series research microscopes, making it essential for laboratories conducting cutting-edge super-resolution microscopy, 3D cell culture imaging, organoid research, and thick tissue imaging. This objective is in new condition, offering top-tier performance for the most demanding research applications.
🔎 Typical Applications
- Super-resolution microscopy (SIM, STORM, PALM)
- 3D cell culture and organoid imaging
- Thick tissue section imaging at depth
- Spheroid and tissue engineering applications
- Confocal laser scanning microscopy (CLSM)
- Live cell imaging in thick specimens
- Multi-channel fluorescence microscopy
- Advanced research microscopy requiring deep tissue imaging
📊 Key Specifications
| Specification | Details |
| Model / Catalog Number | Nikon CFI SR HP Plan Apochromat Lambda S 100X / MRD73950 |
| Magnification | 100X |
| Numerical Aperture (NA) | 1.33 (silicone immersion) |
| Optical Design | SR HP Plan Apochromat Lambda S, Infinity-Corrected (CFI) |
| Immersion Type | Silicone immersion |
| Working Distance | 0.30mm (at 23°C) |
| Coverglass Thickness | 0.15–0.19mm |
| Chromatic Correction | Apochromat (Lambda S series) |
| Thread Type | M25 (25mm metric thread) |
| Compatibility | Nikon CFI infinity-corrected microscopes (Eclipse Ti2, Ni-E, A1 series) |
| Recommended Applications | Super-resolution, 3D cultures, thick tissue, organoids, deep imaging |
| Condition | New |
University purchase orders are welcome and accepted. Please contact us for institutional pricing and procurement assistance.
